RapidManual/RapidLearning: rotate an object with an arrow

This article applies to RapidManual and RapidLearning.

To rotate an object with an arrow, please follow the steps below.

  • Create Remove the threaded fastener (or any other Rotate with Anti–Strobe) action;
  • Refresh Procedure
  • Expand the action and click on the Screw’s value
  • Align the axes so that Y-axis shows the direction of movement while rotating
  • Click Apply, OK, and Refresh Procedure
  • Enable rotation (showRotation: ON)
  • Adjust arrow or screw values as required
